Socket

LGA1150

Chipset

Intel   H81/Q87 PCH

BIOS

AMI   UEFI

DRAM

Technology

DDR3/DDR3L  1600/1333MHz

Capacity

Up   to 16GB

Socket

2 x 204-Pin SO-DIMM Slot

Display

Graphics

Intel   HD Graphics with DX11.1 & OpenCL 1.2

Graphics   Memory

Share   System memory up to1.7GB   SDRAM

VGA

2

HDMI

1   (Ver:1.4)

Multi-Display

2   Independent display

3   Independent display (Q87)

LAN

2 x Intel GbE Controller (i210AT+i211AT)

Audio

Realtek ALC887 w/Line-Out/Line-in/Mic

CD-In

Yes

Watchdog

Software   Programming 1~255s System Reset

TPM

Yes

Storage

SATA

2 x SATA3.0 （6Gb/s）

mSATA

1 (Share with Mini PCIe)

RAID

RAID 0/1 (Only Q87 SKU)

I/O

Serial Port

12 x RS232(COM1&COM2 SupportRS232/422/485)

LPT

N/A

USB

4 x USB3.0 + 6 x USB2.0

GPIO

4-In , 4-Out

PS/2

Yes

Expansion

Slot

PCI

1 (Version: 2.3)

Mini PCIe

2 (One share with mSATA)

Power

Type

ATX Power

Form Factor

170mm x 170mm (Mini-ITX)

Environment

Operation   Temp

&   Humidity

-10~70℃

/10~90%,non-condensing

Storage   Temp

&   Humidity

-20~80℃

/10~90%,non-condensing

Certification

EMC

CE / FCC
